ADDERLink - Portal R110 (DisplayPort)
8 437,00 kr*
2 stycken tillgängliga, leveranstid: 3 - 5 arbetsdagar
Product information "ADDERLink - Portal R110 (DisplayPort)"
Designed for image critical applications, ADDERLink Portal R110 is an ARDx™ technology enabled, ZeroU™ transmitter that provides secure, low-latency keyboard, video, mouse and audio connectivity via the Internet or a local network.
Hardware remote KVM
With HDMI connectivity and USB2.0 for keyboard, mouse and other HID devices. Unlike remote access software it operates out-of-band, enabling BIOS control of the target PC during boot and securely separating remote users from the local network.
High quality audio and video
Experience exceptional media streaming with HD 1920x1200 resolution at ultra-smooth 60Hz frame rates, 4:4:4 accurate color and 16-bit 44.1kHz PCM stereo audio. Fluid motion, pure color and clear text reproduction for image critical applications.
Highly Secure
Enterprise-grade security ensures your connection is safe. AES-256 encryption and RSA-2048 authentication offer the highest level of protection, trusted by security agencies and financial institutions worldwide.
ARDx Enabled
ADDERLink Portal is ARDx enabled and therefore requires ARDx Viewer (download from the ARDx Viewer product page), which provides a seamless user experience and powerful admin tools for managing connections and users.
Seamless User Experience
Inherently low latency provides precision control as though you are operating the host PC directly. On a network with suitable capacity, up to eight users can access concurrently without performance degradation.
Network Capability
For critical performance applications, ADDERLink Portal is optimized for use over a Local Area Network (LAN). Wide Area Network (WAN) connectivity for remote internet access can be achieved through a firewall port or Virtual Private Network (VPN).
Simple Installation
The Zero U dongle form factor requires no rack space. USB power from the host PC means no bulky power supply or spare wall socket is required although an external supply can be used.
Target any OS
Unlike remote access via software, the ADDERLink Portal can control any PC with a KVM connection, regardless of the Operating System. Advantageous for installations where the OS may be considered legacy, or configuration change is prohibited.
PACKAGE CONTENTS:
- 1x ADDERLink Portal unit with DP connector
- 1x Quick Start Guide
| Connection: | USB Port |
|---|---|
| Graphic Port: | DisplayPort |
Features
- Hardware remote KVM
- ARDx Enabled
- High quality audio and video
- Seamless User Experience
- Highly Secure
- Network Capability
- Simple Installation
- Target any OS
Specifications
Video Information (1 Screen)
- Maximum Resolution (1 Screen): 1920 x 1200
- Frame Rate (1 Screen): 60
- Color Depth (1 Screen): 8 bpc
Video Additional Information
- Video Additional Information: HD@60Hz 4:4:4 chroma with dynamic frame-rate back-off under limited bandwidth conditions
Computer Connections
- USB A: 1x 2.0, True Emulation (HID Only)
- Full Size DisplayPort: 1x 1.2
Link Ports
- 8p8c (RJ45) 1x
Audio Connections
- Audio Type: Digital
- Channels: 2x
- Audio Direction: Output only
- Audio Additional Information: Digital Audio 2 channel linear PCM
- Size (bit): 16
- Speed (kHz): 44.1
- Audio In Port: 1x USB
Network Support
- Bandwidth: 1GbE
- 10/100 Support: No
Power Source
- USB powered: 2x
- 5V: 1x
- Power Additional Information: USB Power: 2 x USB A (2x500mA@5V 5W). External Power: 5Vdc, 1A (LPS)
Power Consumption
- Maximum Power (Watts): 5
- Maximum Power (Current): 1
- Typical Power (Watts): 3
- BTU (BTU/hr): 10.2
Physical Design
- Construction Material: ABS and aluminum construction
- U size: 0
- Width (mm) / (in.): 55 / 2.2
- Height (mm) / (in.): 25 / 1
- Depth (mm) / (in.): 110 / 4.3
- Flying Lead Length (mm): 300
- Weight (kg) / (lb): 0.2 / 0.4
Compatibility
- OS Compatibility
- All known operating systems
Approvals and Standards
- Approvals: CE, ICES, UKCA
- Standards: ANSI 63.4, EN/IEC 62368-1, EN55032 /CISPR 32, EN55035/CISPR 35, EN61000-3-2, EN61000-3-3, EN63000, FCC pt15B
- Other: Cal Prop 65, China ROHS, EU REACH, UK REACH
Packing Box
- Length (mm) / (in.): 292 / 11.5
- Width (mm) / (in.): 245 / 9.6
- Depth (mm) / (in.): 55 / 2.2
- Weight (kg) / (lb): 0.5 / 1.1
